Canadian Solar TOPBiHiKu7 CS7N-700TB-AG 700 W Bifacial Module

N-type bifacial TOPCon module, 132 cells, 700 W at STC.

Technical specifications

Rated power (Pmax)	700 W
Max. power voltage (Vmp)	40.0 V
Max. power current (Imp)	17.51 A
Open-circuit voltage (Voc)	47.9 V
Short-circuit current (Isc)	18.49 A
Module efficiency	22.5 %
Power tolerance	0 ~ +10 W
Temperature coefficient (Pmax)	-0.29 % / °C
Cells	TOPCon cells, 132 [2 x (11 x 6)]
Dimensions	2384 x 1303 x 35 mm
Weight	37.9 kg
Junction box	IP68, 3 bypass diodes
Glass (front / back)	2.0 mm heat strengthened glass / 2.0 mm heat strengthened glass
Max. system voltage	1500 V (IEC/UL)
Max. series fuse rating	35 A
Operating temperature	-40°C ~ +85°C
Bifaciality	80 %
Packaging	31 pieces per pallet

Values are reproduced as published in the manufacturer datasheet. Final specifications are confirmed in the quotation.
